Ubiquiti UISP Wave Nano 60GHz PtMP Station Up to 5km Link Range 2Gbps Max Throughput 5GHz 800+Mbps Backup Radio 1x GbE RJ45
£223.99
VAT included
Ubiquiti UISP Wave Nano 60GHz PtMP Station Up to 5km Link Range 2Gbps Max Throughput 5GHz 800+Mbps Backup Radio 1x GbE RJ45 Port Integrated GPS + Bluetooth
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
UISP Wave Nano 60GHz PtMP Station
Introducing the Ubiquiti UISP Wave Nano which can connect to a Wave AP and deliver 2 Gbps total throughput (1 Gbps duplex).
The Wave Nano is equipped with a high-performance 5GHz backup radio to ensure uninterrupted connection and a Bluetooth radio to simplify setup via the UISP Mobile app.
Key Features
5 GHz backup radio
Link range: up to 5 km
Router mode support
Integrated GPS antenna
Link planning support via ISP Design Center
Note: as of firmware 3.2.0-beta2 it is now possible to use two Wave Nano units in a PTP configuration.
Specifications
Mechanical
Dimensions
413 x 413 x 360 mm
Weight
Without Mount
1.5 kg
With Mount
2.7 kg
Enclosure
Aluminium UV stabilised plastic
Hardware
Processor
Quad-Core ARM Cortex A7
Memory
256 MB DDR3
Networking Interface
10/100/1000 Mbps RJ45 Ethernet
RF Connections
Internal
Max. Power Consumption
18W
Power Method
Passive PoE (Pairs 4 5+; 7 8-)
Power Supply
48VDC 0.65A Gigabit PoE Adapter (Included)
Supported Voltage Range
48VDC ± 10%
ESD/EMP Protection
Air/Contact: 24kV
Operating Temperature
-40 to 60° C
Operating Humidity
5 to 95% Noncondensing
Certifications
FCC IC CE
LEDs
Power
Flashing White: Bootup in Progress
White: Not Connected to Ubiquiti® Network Management System (UISP™)
Blue: Connected to UISP
Ethernet
Flashing Blue: Ethernet Trafic Detected
GPS
Blue: Receiving at Least (4) GPS Satellite Signals
System
Maximum Throughput
1.8 Gbps
Maximum Range
12 km in US UK range to be confirmed
Encryption
WPA2-PSK (AES)
Software
OS
airOS
Modes
PtP Only
Services
UISP Ping Watchdog NTP Client System Log
Utilities
Antenna Alignment Tool Discovery Utility Ping Traceroute Speed Test
Network
Bridge Mode
Management interface
Bluetooth management for easy setup over UISP™ App WEB UI
Minimum Software Requirements
Modern Web Browser or Android/iOS Smartphone
Technology
Wave
RF
Operating Frequency (regulatory region dependant)
57 to 71 Ghz
Max Conducted TX Power
21 dBm
GPS
Yes
Channel Bandwidth
2160 1080 Mhz
Antenna Gain
43 dBi
Box Contents
UISP Wave Nano
Pole mount
Allen key
2 x M6 bolts
Jubilee clip
Wall mount + level
2 x wall plugs + M3.5 screws
M3 bolt
PoE injector
UK power cable
Alignment tool
Introducing the Ubiquiti UISP Wave Nano which can connect to a Wave AP and deliver 2 Gbps total throughput (1 Gbps duplex).
The Wave Nano is equipped with a high-performance 5GHz backup radio to ensure uninterrupted connection and a Bluetooth radio to simplify setup via the UISP Mobile app.
Key Features
5 GHz backup radio
Link range: up to 5 km
Router mode support
Integrated GPS antenna
Link planning support via ISP Design Center
Note: as of firmware 3.2.0-beta2 it is now possible to use two Wave Nano units in a PTP configuration.
Specifications
Mechanical
Dimensions
413 x 413 x 360 mm
Weight
Without Mount
1.5 kg
With Mount
2.7 kg
Enclosure
Aluminium UV stabilised plastic
Hardware
Processor
Quad-Core ARM Cortex A7
Memory
256 MB DDR3
Networking Interface
10/100/1000 Mbps RJ45 Ethernet
RF Connections
Internal
Max. Power Consumption
18W
Power Method
Passive PoE (Pairs 4 5+; 7 8-)
Power Supply
48VDC 0.65A Gigabit PoE Adapter (Included)
Supported Voltage Range
48VDC ± 10%
ESD/EMP Protection
Air/Contact: 24kV
Operating Temperature
-40 to 60° C
Operating Humidity
5 to 95% Noncondensing
Certifications
FCC IC CE
LEDs
Power
Flashing White: Bootup in Progress
White: Not Connected to Ubiquiti® Network Management System (UISP™)
Blue: Connected to UISP
Ethernet
Flashing Blue: Ethernet Trafic Detected
GPS
Blue: Receiving at Least (4) GPS Satellite Signals
System
Maximum Throughput
1.8 Gbps
Maximum Range
12 km in US UK range to be confirmed
Encryption
WPA2-PSK (AES)
Software
OS
airOS
Modes
PtP Only
Services
UISP Ping Watchdog NTP Client System Log
Utilities
Antenna Alignment Tool Discovery Utility Ping Traceroute Speed Test
Network
Bridge Mode
Management interface
Bluetooth management for easy setup over UISP™ App WEB UI
Minimum Software Requirements
Modern Web Browser or Android/iOS Smartphone
Technology
Wave
RF
Operating Frequency (regulatory region dependant)
57 to 71 Ghz
Max Conducted TX Power
21 dBm
GPS
Yes
Channel Bandwidth
2160 1080 Mhz
Antenna Gain
43 dBi
Box Contents
UISP Wave Nano
Pole mount
Allen key
2 x M6 bolts
Jubilee clip
Wall mount + level
2 x wall plugs + M3.5 screws
M3 bolt
PoE injector
UK power cable
Alignment tool
NPUBI-WAVENANO-TL01
