- New
be quiet! Power Zone 2 1200W Semi-passive zero-RPM cooling 2 x 90' angled 12V-2x6 connectors and PCIe 5.1/ATX 3.1 compatibility 10-year manufacturer's warranty.
£197.27
VAT included
be quiet! Power Zone 2 1200W Semi-passive zero-RPM cooling 2 x 90' angled 12V-2x6 connectors and PCIe 5.1/ATX 3.1 compatibility 10-year manufacturer's warranty.
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
The be quiet! Power Zone 2 1200W (MPN: BP030EU) is a high-performance fully modular power supply engineered for enthusiast gaming PCs and professional workstations. Designed to meet the latest ATX 3.1 standard it delivers PCIe 5.1 compatibility with native 12V-2x6 connectors for next-generation GPUs. With 80 PLUS Platinum efficiency and semi-passive cooling it provides exceptional power stability efficiency and near-silent operation backed by a 10-year manufacturer’s warranty.
Key Features
Continuous / Peak Power:1200W continuous / up to ~1270W peak
Efficiency:80 PLUS Platinum
Compliance:ATX 3.1 EPS 12V v2.92
PCIe Support:2 x native 12V-2x6 PCIe 5.1 connectors plus 3 x 6+2-pin PCIe connectors
Rail Design:Single high-capacity 12V rail for stable handling of transient power spikes
Cooling:140mm Pure Wings 3 fan with semi-passive zero-RPM mode at low load
Topology:Advanced LLC + SR + DC/DC topology with digital control
Modularity:Fully modular flat and sleeved cables for optimal airflow and clean builds
Warranty:10-year manufacturer’s warranty; MTBF >100 000 hours
Full Technical Specification
Model / MPN:
Power Zone 2 1200W (BP030EU)
Form Factor:
ATX 3.1 (EPS 12V v2.92)
Power Output:
1200W continuous / ~1270W peak
Efficiency Rating:
80 PLUS Platinum
Input Voltage:
100–240VAC
Input Frequency:
50–60Hz
Input Current:
~15A @ 230VAC ~7.5A @ 115VAC
Power Factor:
0.97 at full load (active PFC)
Modern Standby:
Supported; low standby power consumption
Operating Temperature:
Up to 40°C
MTBF:
100 000 hours at 25°C
Rail Operation:
Single 12V rail rated at approximately 100A+
Additional Rails:
+3.3V and +5V auxiliary rails; -12V and +5VSB supported
Hold-up Time:
Compliant with ATX 3.1 specifications
Protections:
OCP OVP UVP OPP OTP SCP surge and inrush protection
Fan:
140mm Pure Wings 3 fan with semi-passive zero-RPM operation
Noise Levels:
Extremely quiet at low to medium loads; increases gradually under sustained full load
Modularity:
Fully modular cable system using flat and sleeved cables
Cable Length:
Up to ~100cm maximum cable length
Connectors:
1 x 20+4-pin ATX
1 x 8-pin CPU (P8 / EPS)
1 x 4+4-pin CPU (P4+4 / EPS)
2 x 12V-2x6 PCIe 5.1
3 x 6+2-pin PCIe
7 x SATA power
1 x PATA (legacy)
Dimensions:
~160 x 150 x 86mm (W x D x H)
Warranty:
10-year limited manufacturer’s warranty
Key Features
Continuous / Peak Power:1200W continuous / up to ~1270W peak
Efficiency:80 PLUS Platinum
Compliance:ATX 3.1 EPS 12V v2.92
PCIe Support:2 x native 12V-2x6 PCIe 5.1 connectors plus 3 x 6+2-pin PCIe connectors
Rail Design:Single high-capacity 12V rail for stable handling of transient power spikes
Cooling:140mm Pure Wings 3 fan with semi-passive zero-RPM mode at low load
Topology:Advanced LLC + SR + DC/DC topology with digital control
Modularity:Fully modular flat and sleeved cables for optimal airflow and clean builds
Warranty:10-year manufacturer’s warranty; MTBF >100 000 hours
Full Technical Specification
Model / MPN:
Power Zone 2 1200W (BP030EU)
Form Factor:
ATX 3.1 (EPS 12V v2.92)
Power Output:
1200W continuous / ~1270W peak
Efficiency Rating:
80 PLUS Platinum
Input Voltage:
100–240VAC
Input Frequency:
50–60Hz
Input Current:
~15A @ 230VAC ~7.5A @ 115VAC
Power Factor:
0.97 at full load (active PFC)
Modern Standby:
Supported; low standby power consumption
Operating Temperature:
Up to 40°C
MTBF:
100 000 hours at 25°C
Rail Operation:
Single 12V rail rated at approximately 100A+
Additional Rails:
+3.3V and +5V auxiliary rails; -12V and +5VSB supported
Hold-up Time:
Compliant with ATX 3.1 specifications
Protections:
OCP OVP UVP OPP OTP SCP surge and inrush protection
Fan:
140mm Pure Wings 3 fan with semi-passive zero-RPM operation
Noise Levels:
Extremely quiet at low to medium loads; increases gradually under sustained full load
Modularity:
Fully modular cable system using flat and sleeved cables
Cable Length:
Up to ~100cm maximum cable length
Connectors:
1 x 20+4-pin ATX
1 x 8-pin CPU (P8 / EPS)
1 x 4+4-pin CPU (P4+4 / EPS)
2 x 12V-2x6 PCIe 5.1
3 x 6+2-pin PCIe
7 x SATA power
1 x PATA (legacy)
Dimensions:
~160 x 150 x 86mm (W x D x H)
Warranty:
10-year limited manufacturer’s warranty
